NOMAD Voyager Mobile Energy Storage
The Voyager series is a family of three transportable battery energy storage systems from NOMAD Transportable Power Systems. All three share a common architecture: LFP battery chemistry, a 20 foot containerized enclosure, a semi trailer chassis, and 480V output.
Specifications
| Voyager Eagle | Voyager Falcon | Voyager Hawk | |
|---|---|---|---|
| Power output | 999 kW | 500 kW | 500 kW |
| Storage capacity | 2.0 MWh | 2.0 MWh | 1.0 MWh |
| Discharge duration | Approx. 1.7 hours at 999 kW | Approx. 3.5 hours at 500 kW | Approx. 1.7 hours at 500 kW |
| Voltage | 480V | 480V | 480V |
| Chemistry | LFP | LFP | LFP |
| Container | 20 ft x 8 ft x 9.5 ft | 20 ft x 8 ft x 9.5 ft | 20 ft x 8 ft x 9.5 ft |
| With trailer | 36.7 ft x 8 ft x 13 ft | 36.7 ft x 8 ft x 13 ft | 36.7 ft x 8 ft x 13 ft |
| Weight with trailer | 65,700 lbs | 65,600 lbs | 48,700 lbs |
| Weight without trailer | 55,000 lbs | 55,100 lbs | 38,000 lbs |
| Deployment | Under 1 hour | Under 1 hour | Under 1 hour |
Specifications as published by NOMAD Transportable Power Systems, September 2026, and subject to change. Weights exclude transformer.
Common Platform Features
- Lithium iron phosphate (LFP) battery chemistry
- Active liquid cooling
- Grid-forming capability (Voyager Eagle)
- UL 9540A tested, as stated by NOMAD
- 24/7 monitoring through NOMAD’s Network Operations Center
- Remote diagnostics, predictive maintenance, and firmware updates
- Engineered and built in Vermont
Selecting a Unit
The Eagle suits applications that need high power for shorter periods, such as grid support and large industrial loads. The Falcon suits applications that need sustained output, such as peak shaving, diesel hybrid operation, and renewable integration. The Hawk suits construction, events, and backup power. GEL sizes each system against actual load data before recommending a unit.
